1. The water booth size is W2000mm×D1800mm×H2000mm
2. Downdraft design
3. The bottom bracket is made of 50X50 stainless square box section and equipped wit h the adjustable M14 foot cup.
4. The tank is made by bending and welding 1.5mm 201# stainless steel sheets.
5. The top and side plates is made by bending and welding 1.2mm 201# bending and welding stainless steel sheets.The top and side plate are connected with stainless steel sc rews.
6. The real plate and overflow tank are made by bending and welding 1.2mm 201# stai nless steel sheets.
7. The water curtain plate are made by bending and welding 1.0mm 201# stainless stee l sheets.
8. The pump adpots the taiwan vertical pipeline pump. A set of PVC pipe and valve ar e also equipped.the valves are provided for main and secondary water pipers. The piper i n the sink use loose joint for easy removal.
9. The exhaust fan use a set of Taiwan hongsheng 3HP centrifugal fan.(the air volume i s 9000 cubic meters per hour).The ventilation duct is not included and provided by the c ustomer.
10. The light use 2 pcs 40W explosion-proof light with hood.
11. A set of electric control cabinet is equipped and the electrical accessories use the w ell-known brand.
12. The filtration system in the top of booth use the non-woven filter screen
